Rendimiento del producto:
Productos patentados de desarrollo propio, cortadora de alta velocidad de etiquetas estrechas, sistema de tensión cónica de bobinado servo completo de alta gama, sistema de corrección de procesos de marcas famosas importadas, con funciones de conteo y conteo de metros, menos desaceleración o estacionamiento de material y soporte para tratamiento electrostático.
|
Type |
450 slitting rewinding machine |
|
Cutting speed |
400m/min |
|
Max web width |
450mm |
|
Max unwinding diameter |
600mm |
|
Max rewinding diameter |
600mm |
|
Min cutting width |
15mm |
|
The cutting precision |
+-0.5mm |
|
Overall diameter |
1600x1200x1800mm |
|
The main motor power |
2.2kw |
|
Weight |
1400kg |
|
Voltage |
380v |
|
Total power |
9.5kw |
Configuration of slitter:
|
Item |
Name |
Model Specification |
Quantity |
Product Name |
|
1 |
Unwinding shaft |
Unwinding automatic servo constant tension |
1 |
xinjie |
|
2 |
Traction rod power |
2.2kw servo motor control 1 |
1 |
xinjie |
|
3 |
Fan |
0.75kw |
1 |
shanghai yumao |
|
4 |
Button switch |
Imported Schneider |
10 |
Schneider |
|
5 |
Deviation correction system |
Deviation correction machine w500 |
1 |
enruisi |
|
6 |
Touch screen |
7寸 |
1 |
xinjie |
|
7 |
Pneumatic valve |
jiaer |
5 |
|
|
8 |
Up winding |
Up winding automatic servo constant tension (2.2kw) |
1 |
xinjie |
|
9 |
Lower rewinding |
Lower winding Automatic servo constant tension (2.2kw) |
1 |
xinjie |
Project Name Model Specification Quantity Product Name
1. (2.2kw) 1 Xinjie
2. Independent Xinjie
3 Fan 0.75kw 1 Shanghai Yubao
4 button switch 10 Schneider
5 1 Enris
6 7 inch 1 Xinjie
7 Jiaer 5
8. 1 Xinjie
9 1 Xinjie
