Configuration：
|
Mechanical part |
Electrical part |
|
1.Unwinding device: one unwinding edger, one ordinary unwinding rack, fixed with cone sleeve
manual lock |
1.Thehostadoptsvariablefrequencyspeedregulation (1.5kw), and the inverter uses Hualan |
|
2.Frame: 10mm steel plate structure |
2.one servo motor (Delta) for feeding |
|
3.Cross-cutting knife holder: using casting structure |
3.Traction uses two pcs 0.75KW inverter motors |
|
4. Cross-cutting knives: using domestic common cutters |
4.Photoelectrictrackingandpositioningdevice(Zhejiang Julong) |
|
5. Drive shaft: grooved by rubber shaft 6. Hot knife:Usecopper knife (2 two horizontal irons, 2 vertical irons) |
5.Independentmicrocomputercontrolcabinet: Automatic counting, automatic alarm when the number is reached. Automatic stop function |
|
7.Feeding traction method: the motor drives the pulley to drive the traction rubber shaft (Two traction rubber rollers and two discharge racks) |
6.Computer (touch screen control) |
|
8.Max bag width is 1000mm Max bag length is 600mm |
7.The host uses a motor 1.5KW with a reduction motor (Shanghai) |
|
9. Machine weight: 1700kg |
8.Mechanical speed: 120 pcs / min |
|
Dimensions: length 4.5 meters * width 1.2 meters * height 1.8 meters |
|
