TWO, instruction:
1. Printing color:6 color (Arbitrarily increase or decrease)6+0，5+1，4+2，3+3；
2. Max. Mechanical Speed:90m/min；
3. Max. Printing Speed：70m/min；
4. Metal anilox roller
5. Accuracy of Registration:vertical±0.35mm(manual operation)
6. Broadwise:±0.35mm(manual operation)
7Max. Diameter ofRoll Material:Ø600mm
8. Air shaftØ76 mm(internal diameter)
9. Printing Pressure: Mechanical adjustment
10. Embossing roller:Ø127.4mm
11. Drying methods: electrical heating
12. Drying power:18KW
13. Fans :0.55KW for3pcs；
14. Main motor:3.7KW；
15. Maininverter made in China
16. The ink motor:Synchronous motor transport ink；
17. Tormalbearing: Made in China
18. Single bearing: Made in China
19. Aluminium wheel: enable to oxidation and dynamic and static balance
20. E.P.C: Auto correction device one piece；
21. Tension control system:Control of magnetic powder for collecting and releasing materials
22. Raise-drop version: the pressure raise-drop version
23. Electric: China CHINT
24. Total power:25kw
25. Rang of printing length: 250mm-1000mm
26. Plate thickness:1.7mm；
27. Max web width:1000mm
28. Printing width:960mm
29. Printing roller:one color one stick ,max printing length300mm
30. Ssubstrates material: plastic ,roll paper, non-woven fabric
31. Air shaft：4pcs；
32. Overall dimensions：L 4.8×W 2.3×H 3.1m；
33. Weight（about）：4.5T。
THREE,Features:
1. Easy operation, flexible starting, accurate color register.
2. Adopted motor, frequency control of motor speed, saveelectricity, Small fluctuation
3. When drop version ,automatically stop transported ink motor, it will automatically begin to transport ink device when raise version
4. The way of transport the ink is through therubber covered roller scraping
5. Adopted a special straight geardrive, Printing sizeisaccuracy
6. It equipped with 2 set of devices, blowing and heating , and the heatingadopted center constant temperature control system and group control
7. Low stick with steel processing, And after the special craft processing, andelectroplate 3wire thickness super hard chromium plating of protection
8. Aluminium wheel: enable to oxidation and dynamic and static balance
9. It has equipped with an box which cold air qualitative, it can effectively prevent the ink adhesion defect after printing
10. The printed image is clear, Folding accuracy,high rate of finished products
11. Automatically counter , the machine stop when the material is cut off, automatically transported the ink when the machine stop, but the ink motor automatically stops when printing。
FAQ:
Q: Can you design the machine according to our requirements?
A: Yes. We not only can customize the machine according to your technical drawing, but also can make new machine according to your requirements.
Q: Can you offer overseas technical support?
A: Yes. We can send engineer to your company to set the machine and train your worker if needed.
Q: Do you have manual or operation video for us to know more about the machine?
A: Yes, not only manual or operation video, 3D drawing also available to make as per your design,also the video we can make of testing the material from our machine if your goods easier for us to find from our local market.
Q: How can I trust you for the first time business ?
A: Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.
Q: Will you provides the door to door service?
A: Yes. Please offer us your final destination, we will check with our agent to see if it available, and most of the area is ok for us to clearing and sending in your countries.
