Performance and characteristics:
1. The whole machine is controlled by microcomputer and hauled by stepping motor (servo motor control system is optional).
2. Any fixed length, step photoelectric tracking, accurate and stable, automatic stop when losing standard, photoelectric control for feeding.
3. Automatic counting and settable counting alarm.
4. The bag mouth is sealed firmly and smoothly with automatic constant temperature.
5. Double layer double ironing knife, one time up to four blank bags (no printing).
Main technical parameters:
|
Model |
SM-600 |
SM-800 |
SM-1000 |
SM-1200 |
|
Max.bag width（mm） |
550 |
780 |
980 |
1180 |
|
Max.cutting length（mm） |
1000 |
1000 |
1500 |
1500 |
|
Speed (pcs/min) |
120-280 |
120-280 |
120-280 |
120-280 |
|
Total power |
4.5 |
4.7 |
5.3 |
5.5 |
|
Machine weight |
950 |
1050 |
1150 |
1250 |
|
Overall (LxWxH) |
2650×1100×1900mm |
2650×1300×1900mm |
2750×1600×2000mm |
2850×1800×2000mm |
