Usage: This machine issuitable for heat cutting and bag making of such printed or without printed plastic film asOPP, PP and PE, etc. It’s an idealquipment for envelope bag, pillowcase bag, garment bag, towel bag andaccessory bag.Ideal equipment for making bags of folded film or double-layer materials).
Features:
1. The wholemachine adopt microcomputer control, frequency control andmaterial feeding byservo motor;
2. Arbitrary fixed-length, accurate and stable stepPhotoelectric tracking, stopping automatically when the label is lost.
3. Auto-Sync double adhesive tape processing, automatic punching and automatic stopwhen run out of materials.
4. Heat sealing decorative border, automatic constant temperature, firm and flat sealing.
5.Optional deviation correction feeding rack.
Main technical parameters:
|
Model |
DRQ-500 |
DRQ-700 |
DRQ-800 |
DRQ-1000 |
|
制袋长度 Max.Cutting Length |
50-650mm |
60-650mm |
70-650mm |
70-650mm |
|
制袋最大宽度 Max.Width of base material |
≤500mm |
≤700mm |
≤800mm |
≤1000mm |
|
制袋厚度 Bag making thickness |
0.015-0.05MM |
0.015-0.05MM |
0.015-0.05MM |
0.015-0.05MM |
|
制袋速度 Capacity |
60-220 PCS/MIN |
60-20 PCS/MIN |
60-200 PCS/MIN |
60-200 PCS/MIN |
|
The widest feeding of film folding machine |
≤1150MM |
≤1350MM |
≤1550MM |
≤1950MM |
|
总功率 Total power |
4KW |
5KW |
6K |
6KW |
|
机械重量 Mechanical weight (approx.) |
1000KG |
1100KG |
1200KG |
1300KG |
|
制袋机械尺寸 Bag making machine size (approximate) |
4000×1200×1900mm |
4000×1400×1900mm |
4000×1500×1900 mm |
4000×1500×1900 mm |
