MD-800 High Speed PE Automatic Zipper Machine

Product Application:

Application: It is applicable to the automatic zipper bag of PE, PP, OPP, BOPP and other plastic materials, and the packaging of knitting, clothing, food, stationery and so on. It is an advanced bag making equipment instead of imported similar products at present.

Technical indicators and main parameters:

Technical indexes and main parameters

Model

MD-800 high speed PE automatic zipper machine

Machine speed

20~150pcs/min

Bag width

50~700mm

Bag length

50~700mm

Bag making thickness

3~10

Voltage

220v/380V

Total power

9kw

Overall dimension

8000×1300×1900mm

Complete machine

Weight

2080KG

Knife

It is equipped with a set of hot zipper forging copper knife, a set of bag cutting forging imported steel knife and a set of cold knife

Unwinding unit

Unwinding diameter

600mm (with automatic deviation correction, automatic magnetic particle constant tension, automatic feeding and automatic shutdown without material)



Pneumatic punch

Round hole1 pc

Conveyor belt

Imported Kodak brand

Automatic photoelectric tracking

Imported from Germany

Electric control system of the whole machine

Special multi motor tension drive system stepping motor Songyang brand (servo motor can be used)

Variable frequency reduction motor

Guangdong Wanxin

Relay

OMRON

Pneumatic components

Yadeke, Shenzhen, etc



Automatic make-up vibrating plate

Guangdong



Ultrasonic bag mouth flattening reinforcement

Guangdong

Common electrical appliance brands

Temperature display instrument

Thermometer made in Shanghai for displaying the surface temperature of preheating roll

Common electrical components / switches

Chint electric

Frequency converter

Changsha beishide

Computer touch screen

Taiwan Weilun

PLC

Mitsubishi

Variable frequency motor

Shanghai Suchuan

Producible product

Bearing

Mostly imported from Japan

List of free accessories

 1 temperature control line, 1 high-temperature cloth, 50 springs, random accessories, a set of toolbox, an oil gun, 1 temperature control meter, 1 heating tube and 1 switch. All instructions of this machine.

Application: it is applicable to the automatic zipper bag of PE, PP, OPP, BOPP and other plastic materials, and the packaging of knitting, clothing, food, stationery and so on. It is an advanced bag making equipment instead of imported similar products at present.
