Features:
1. The wholemachine adopt microcomputer control, frequency control andmaterial feeding byservo motor;
2. Arbitrary fixed-length, accurate and stable stepPhotoelectric tracking, stopping automatically when the label is lost.
3. Auto-Sync double adhesive tape processing, automatic punching and automatic stopwhen run out of materials.
4. Heat sealing decorative border, automatic constant temperature, firm and flat sealing.
5. Optional deviation correction feeding rack.
Technical parameters:
|
Model |
DRQ-500 |
DRQ-700 |
DRQ-800 |
DRQ-1000 |
|
Max.Cutting Length |
50-650mm |
60-650mm |
70-650mm |
70-650mm |
|
Max.Width of base material |
≤500mm |
≤700mm |
≤800mm |
≤1000mm |
|
Bag making thickness |
0.015-0.05MM |
0.015-0.05MM |
0.015-0.05MM |
0.015-0.05MM |
|
Capacity |
60-220 PCS/MIN |
60-20 PCS/MIN |
60-200 PCS/MIN |
60-200 PCS/MIN |
|
The widest feeding of film folding machine |
≤1150MM |
≤1350MM |
≤1550MM |
≤1950MM |
|
Total power |
4KW |
5KW |
6K |
6KW |
|
Mechanical weight (approx.) |
1000KG |
1100KG |
1200KG |
1300KG |
|
Bag making machine size (approximate) |
4000×1200×1900mm |
4000×1400×1900mm |
4000×1500×1900 mm |
4000×1500×1900 mm |
