1. Printing color number: 2 colors (any increase or decrease) 2 + 0, + 1 + 1;
2. Maximum mechanical speed: 90 m / min;
3. Mamxium printing speed: 70 m / min;
4. Roller: metal roller;
5. Registration accuracy: longitudinal ±0. 2 mm (manual);
6. Horizontal: ±0. 15mm (manual);
7. Winding and unwinding: diameter φ 600mm, single release and single collection;
8. Reel in / reel out paper / rubber cylinder: Manual φ 76 mm (inner diameter);
9. Imprint force: mechanical adjustment;
10. Imprint roll: φ 127.4mm；
11. Drying method: electric heating;
12. Drying power: 9kw;
13. Fans: 0.55kw;
14. Main motor: 1.5kw;
15. Main frequency converter: made in China;
16. Ink motor: synchronous motor ink;
17. Ordinary bearing: made in China;
18. One way bearing: made in China;
19. The aluminum alloy guide wheel is treated by oxidation, dynamic balance and static balance;
20. Deviation correction system: automatic edge correction matching;
21. Tension control system: magnetic powder control (automatic tension matching);
22. Landing plate: 1 set of cylinder device landing plate;
23. Main electrical appliances: Chint or Delixi;
24. The power of the whole machine is (about) 12KW;
25. Print length range: 200 MM-1000 mm;
Plate thickness: 2.28mm;
Maximum print width: 800mm;
Maximum printing width: 760 mm;
Printing stick: the effective length of printing is 300-400mm, one for each color;
Selection of tension shaft;
Manual version matching;
Printing materials: plastic, web, non-woven fabric.
Main features:
1. Easy to operate, easy to put, accurate coloring, long service life
2. Motor, frequency control, power saving and small fluctuation
3. The inking motor will stop automatically when the plate is down, and the inking device will start automatically when the plate is up
4. The ink supply mode is cot scraping
5. Special module helical gear transmission is adopted, and the printing size is accurate,
6. There are two sets of blowing and heating devices, in which the heating adopts the central constant temperature control system and group control
7. The low rod is made of steel and treated by special process, and plated with 5-wire thick hard chromium protective layer
8. Hard oxidation, dynamic balance and static balance treatment for aluminum alloy guide wheel
9. It is equipped with cold air shaping bellows, which can effectively prevent ink adhesion and other defects after printing
10. Clear printing image and accurate folding
11. Printing, folding and dividing into one, high production efficiency and high yield
12. Automatic counter, stop the machine automatically when the material is broken, stop the machine automatically to transport the ink, and stop the ink motor automatically when printing
Weight (about): 1.8 tons
Overall dimension (about): length 3 × Width 1.9 × It is 2.4 meters high.
